--- # Status of CERN Authentication and Authorisation ##### Asier Aguado Corman, Hannah Short, Adeel Ahmad, Maria Fava, Sebastian Lopienski, Antonio Nappi, Paolo Tedesco ###### HEPiX Spring 2023 --- # Summary 1. Our service 2. Architecture summary 3. Single Sign-On software and customisations 4. Special authentication use cases 6.1. Machine to machine authentication 6.2. Command line access 5. Two-factor authentication 6. Other challenges and future roadmap --- ### What our service offers **Identity Management** Identity and account lifecycle. <img src="https://codimd.web.cern.ch/uploads/upload_c796daec5e675b27d9016911f557a95a.png" height="350px"> ---- **Authentication and Authorisation** - Single Sign-On - OAuth, OpenID Connect and SAML. - Groups, Roles and levels of access/assurance (LoA). - X.509 Certificate Authorities - Not covered in this presentation. <img src="https://codimd.web.cern.ch/uploads/upload_5d555f0464dd92e898b242b6f094dbff.png" height="350px"> ---- **Computing Resource management** - Manage computing resource ownership - Such as websites, database accounts. - Automatically reassign or delete resources - Based on elegibility (e.g. no longer at CERN). <img src="https://codimd.web.cern.ch/uploads/upload_6a0ea33668b93b28093a3e43c53a1066.png" height="350px"> --- ### Current usage - 35,000 individual users - 25,000 logins per day - **More than 9,000 applications and websites** --- ### CERN AAI Architecture  --- ### Single Sign-On - Based on the open source product [Keycloak](https://www.keycloak.org/) - Uses OpenID Connect (OIDC) and SAML standards - Replaces the old SSO based on ADFS - Customised to fit our use case <img src="https://codimd.web.cern.ch/uploads/upload_5d555f0464dd92e898b242b6f094dbff.png" height="350px"> --- ### Overall Impression - Positives - Upstream project of [Red Hat Single Sign-On](https://access.redhat.com/products/red-hat-single-sign-on) - [Keycloak community](https://www.keycloak.org/community) is very active - Project [applied to CNCF](https://github.com/cncf/toc/pull/463) for incubation - Good compliance with OIDC and SAML standards - More focus on OIDC - More features are getting added - The initial releases needed more customization - Scalability and performance have improved  ---- - Negatives - Occasional bugs causing some integrations to break - [Recent bug in SAML response](https://github.com/keycloak/keycloak/issues/14529) affecting the Microsoft federation - It was resolved very quickly - Uncertainty about future database support - MySQL and Oracle [will be dropped](https://www.keycloak.org/2022/02/dbs) --- ### SSO Customisations - Keycloak extensions: Service Provider Interfaces (SPIs) - Mappers to fetch user properties externally - Groups and Roles from outside Keycloak - Custom Level of Assurance implementation (before LoA was introduced in Keycloak) - Endpoint to get API tokens for any audience: uses Client Credentials Grant with an `audience` field - Endpoint to validate OTP codes: we use it together with a PAM module for 2FA over SSH - Compromised password detection: we compare input passwords with a database of leaked passwords. This allowed us to stop annual password changes. ---- - Keycloak Configuration - Optional 2FA in a second realm: we will move to step up 2FA now that is has been introduced - Account management is disabled: we use our own external database, API and portals - Wrappers - A Keycloak REST Adapter developed over the Keycloak Admin API, e.g. to reset 2FA. This was made available on Github for other communities. ---- #### Application Portal Users can register their applications in this portal.  ---- #### 2FA settings in Users Portal Account console is disabled in Keycloak.  ---- #### HTTP Endpoint to verify 2FA codes Adds new possibilities for two-factor authentication. ``` $ ssh aaguadoc@aiadm.cern.ch (aaguadoc@aiadm.cern.ch) Your 2nd factor (aaguadoc): 123456 ``` --- ### Machine to machine authentication A service authenticates to another service where it **doesn't necessarily have control or credentials**. - Old approach: Cookie based authentication, using a command line tool logs into the SSO using Kerberos and SPNEGO and saves cookies into a file. - We developed the same tool for the new SSO. - Modern approach: OAuth2 and JWT. - OAuth2 Client Credentials Grant. - Custom _API Access_ endpoint to replace audiences. - Role based access control ---- Before: ``` $ kinit -t myservice.keytab myservice@CERN.CH $ auth-get-sso-cookie -u https://myapi.cern.ch -o cookies.txt $ curl -L -b cookies.txt https://myapi.cern.ch/foobar ``` Now: ``` $ curl --location --request POST "https://auth.cern.ch/auth/realms/cern/api-access/token" \ --header 'Content-Type: application/x-www-form-urlencoded' \ --data-urlencode 'grant_type=client_credentials' \ --data-urlencode "client_id=my-client-id" \ --data-urlencode "client_secret=bdebbdcc-c33c-11ed-b0a8-3822e22949e4" \ --data-urlencode "audience=myapi" | jq -r .access_token > token.txt $ token=$(<token.txt) $ curl -X PUT "https://myapi.cern.ch/api/foobar" -H "authorization: Bearer $token" -d "{\"foo\": \"bar\"}" ``` --- ### Command line access Accessing protected web resources from a CLI through `wget`, `curl` or similar. - Old approach: Same command line tool as in the previous use case - Modern approach: OAuth2 Device Authorization Grant. - Users log in using a web browser window outside the terminal. - Positive: Compatible with all modern 2FA protocols. - Negative: Resistance towards moving to this because it requires a round trip to a browser ---- Before: ``` $ kinit Password for aaguadoc@CERN.CH: $ auth-get-sso-cookie -u https://the-target-api.cern.ch -o cookies.txt $ curl -L -b cookies.txt https://the-target-api.cern.ch/foobar ``` Now: ``` $ auth-get-user-token -c myapi -x -o token.txt CERN SINGLE SIGN-ON On your tablet, phone or computer, go to: https://auth.cern.ch/auth/realms/cern/device and enter the following code: KFRX-JXIV You may also open the following link directly and follow the instructions: https://auth.cern.ch/auth/realms/cern/device?user_code=KFRX-JXIV Waiting for login... $ token=$(<token.txt) $ curl -X PUT "https://myapi.cern.ch/api/foobar" -H "authorization: Bearer $token" -d "{\"foo\": \"bar\"}" ``` --- ### Two-factor authentication The new SSO supports - Authenticator Applications (OTP) - Security Keys and other hardware (WebAuthn) <img src="https://codimd.web.cern.ch/uploads/upload_368366782a89bc3ee97e988ea2509e72.png" height=250px> <img src="https://codimd.web.cern.ch/uploads/upload_d9e43a3e66637f177e163b68bc60d3d7.png" height=250px> ---- #### New 2FA strategy - CERN was previously using step-up 2FA, which was not supported by Keycloak. - We decided to enforce 2FA to every login of a critical account: - Defined _critical users_ instead of _critical applications_. - The change was well received by users who already used 2FA daily. - Poor reception by users who occasionally used _critical applications_, 2FA on every login means less convenience (especially for mobile). ---- - Possible changes after user feedback: - Step up 2FA defined by critical applications. - Non-critical users can opt-in for _always-on_ 2FA. - Reassess critical user membership. --- ### _Always-on_ 2FA Rollout September 2022: About 1600 users March 2023: **2248 users** --- ### 2FA Support Cases - TOTP cases where phone clock out of sync and codes invalid. - Some clash between Yubikeys and native Windows/Mac WebAuthn fingerprint protocol. - Plenty of lost tokens. Procedure established where the security team can verify an identity over Zoom before resetting the token. <img src="https://codimd.web.cern.ch/uploads/upload_d9e43a3e66637f177e163b68bc60d3d7.png" height=200px> <img src="https://codimd.web.cern.ch/uploads/upload_368366782a89bc3ee97e988ea2509e72.png" height=200px> --- ### Other challenges - Growing number user sessions - Mitigated with built-in user session limit - High (and growing) number of clients (applications) - Number of clients seems usually lower in the Keycloak community - Performance issues in the past, it is getting better --- ### Impact of Keycloak 19 upgrade <img src="https://codimd.web.cern.ch/uploads/upload_4feafb650e605e1efd1b00e2d877f57d.png" height="250px"> <img src="https://codimd.web.cern.ch/uploads/upload_85f1a26fed3bc10b0449ee901e76ed77.png" height="250px"> --- ### Old to new SSO migration status  --- ### Future roadmap - Decomissioning old SSO by H2 2023 - Moving Keycloak to Kubernetes by H2 2023 - Remove the second realm for 2FA - More details on our [documentation page](https://auth.docs.cern.ch/#roadmap) <img src="https://codimd.web.cern.ch/uploads/upload_ceeb0b5f6a2c07a8adf82a23cbe4a803.png" height="200px"> <img src="https://codimd.web.cern.ch/uploads/upload_9e3c03a3de48cae99f655ed2fec1b76c.png" height="200px"> ---
